The pancake class is one machine sold by six brands at 2.6 CFM - with one exception that reaches 4.0. Here is how to choose when the flow figure is effectively fixed.

By Ryder M.Last updated Published
A pancake air compressor on a job site with hose attached

Some links on this page are affiliate links. If you buy through one, Magoo Media Group earns a commission from the retailer at no extra cost to you. It never changes which product we rank first - how this site is funded.

The class explained

Why they all have the same specs

A pancake compressor is a flat horizontal tank with a direct-drive oil-free pump on top. The format exists because it is stable, stackable and light, and the 6-gallon size exists because it is the largest tank a 10-amp 120V motor can fill in a tolerable time.

That electrical ceiling is why five of the six units on this page publish exactly 2.6 CFM at 90 PSI. It is not brand laziness; it is the output of the motor and pump combination the format allows. Comparing pancakes on flow is mostly comparing identical numbers.

So the real differences are the pressure ceiling, the published noise figure, weight, and what is in the box. Three of those are specs you can look up. One - noise - is not published by two of the six brands, which is itself a data point.

The pancake field on published specs
CompressorCFM @ 90Max PSIdBAWeight
Metabo HPT EC914S4.0200Not published41 lb
DEWALT DWFP551262.616575.530 lb
Bostitch BTFP020122.615078.5Not published
Porter-Cable C20022.6150Not publishedNot published
Craftsman CMEC6150K2.61508230 lb
WEN AP60922.6150Not publishedNot published

Ranked

The picks

Quick picks

#ProductBest forScorePrice
1
A jobsite pancake air compressor with a wrapped hose on concrete
DEWALT DWFP551262.6 CFM @ 90 / 6 gal / 165 PSI / 75.5 dBA165 PSI instead of 150, at 75.5 dBA and 30 lb. The extra 15 PSI is free tank storage.
The pancake to buy if you are choosing on numbers alone4.0/10★★☆☆☆
Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

2
A high-capacity pancake air compressor with a roll cage
Metabo HPT EC914S (THE TANK)4 CFM @ 90 / 6 gal / 200 PSI4.0 CFM at 90 PSI and 200 PSI max - the only 6-gallon unit here that breaks the 2.6 CFM ceiling.
Getting real CFM without moving up to a 20-gallon footprint5.1/10★★★☆☆
Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

3
A yellow and black pancake air compressor with hose connected
Bostitch BTFP020122.6 CFM @ 90 / 6 gal / 150 PSI / 78.5 dBA2.6 CFM at 78.5 dBA published - quieter on paper than most of the pancake class at the same output.
A pancake for someone who has to work near neighbors3.2/10★★☆☆☆
Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

4
A red six-gallon pancake air compressor on a garage floor
Porter-Cable C20022.6 CFM @ 90 / 6 gal / 150 PSIThe default answer to 'cheapest useful compressor'. 6 gallons, 2.6 CFM, 150 PSI, and it has been the same machine for years.
A first compressor for nailing, inflation and burst automotive work3.6/10★★☆☆☆
Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

5
A pancake air compressor with hose and accessory fittings laid out beside it
Craftsman CMEC6150K2.6 CFM @ 90 / 6 gal / 150 PSI / 82 dBASame 2.6 CFM as every other pancake, bundled with the 13 accessories you would otherwise buy separately.
Buying your first compressor and your first fittings in one go3.7/10★★☆☆☆
Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

6
A compact oil-free pancake compressor with two gauges
WEN AP60922.6 CFM @ 90 / 6 gal / 150 PSIThe cheapest way to get the standard 2.6 CFM / 150 PSI pancake spec. That is the whole pitch.
Spending the least possible to reach the useful 6-gallon spec3.6/10★★☆☆☆
Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Scores are computed from manufacturer-published specs by the rubric on our methodology page. Nothing here has been bench-tested, and we do not publish prices we cannot verify.

Pick 1 - DEWALT DWFP55126

4.0/10★★☆☆☆

DEWALT DWFP55126

Best for: The pancake to buy if you are choosing on numbers alone

Verdict

165 PSI instead of 150, at 75.5 dBA and 30 lb. The extra 15 PSI is free tank storage.

What it does well

  • 165 PSI max is the highest in the 6-gallon class here, which means more stored air per fill
  • 75.5 dBA published - the quietest of the pancakes we list
  • 0.9 HP with a 10 A draw, so it starts on a normal household circuit

What it will not do

  • 2.6 CFM at 90 PSI is the same as every cheaper pancake; the gain is storage, not flow
  • 30 lb with no wheels
How this 4.0 was calculated
MetricScoreWeightBasis
Air flow3.640%2.6 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air2.625%6 gal x 165 PSI = 990, on a 125-3,500 scale
Noise3.515%75.5 dBA, on a 58-85 dBA scale
Portability8.610%30 lb, on a 20-90 lb scale
Spec transparency5.010%3 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)
A jobsite pancake air compressor with a wrapped hose on concrete

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

DEWALT DWFP55126 published specifications
CFM @ 90 PSI2.6
CFM @ 40 PSINot published
Tank6 gal
Max pressure165 PSI
Noise75.5 dBA
Duty cycleNot published
RecoveryNot published
PumpOil-free
Motor0.9
Weight30 lb
Power120V

Source: DEWALT DWFP55126 - product specifications

Pick 2 - Metabo HPT EC914S

5.1/10★★★☆☆

Metabo HPT EC914S (THE TANK)

Best for: Getting real CFM without moving up to a 20-gallon footprint

Verdict

4.0 CFM at 90 PSI and 200 PSI max - the only 6-gallon unit here that breaks the 2.6 CFM ceiling.

What it does well

  • 4.0 CFM at 90 PSI is 54% more air than the rest of the 6-gallon class
  • 200 PSI max means the same 6 gallons holds far more usable air
  • Clears the published average demand for a 1/2-inch impact and a 3/8-inch ratchet

What it will not do

  • 41 lb, the heaviest 6-gallon unit in the roster
  • Metabo HPT does not publish a noise figure, and high-pressure pumps are not quiet
How this 5.1 was calculated
MetricScoreWeightBasis
Air flow6.240%4 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air3.225%6 gal x 200 PSI = 1200, on a 125-3,500 scale
Noise5.015%Manufacturer publishes no dBA figure - scored a neutral 5, not a guess
Portability7.010%41 lb, on a 20-90 lb scale
Spec transparency3.310%2 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)
A high-capacity pancake air compressor with a roll cage

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

Metabo HPT EC914S (THE TANK) published specifications
CFM @ 90 PSI4
CFM @ 40 PSINot published
Tank6 gal
Max pressure200 PSI
NoiseNot published
Duty cycleNot published
RecoveryNot published
PumpOil-free
MotorNot published
Weight41 lb
Power120V

Source: Metabo HPT EC914S THE TANK - product specifications

Pick 3 - Bostitch BTFP02012

3.2/10★★☆☆☆

Bostitch BTFP02012

Best for: A pancake for someone who has to work near neighbors

Verdict

2.6 CFM at 78.5 dBA published - quieter on paper than most of the pancake class at the same output.

What it does well

  • 78.5 dBA published, against 82 for the Craftsman at the same 2.6 CFM
  • High-efficiency cold-start motor, which matters in an unheated garage
  • 150 PSI, 6 gallons - standard useful storage

What it will not do

  • Still noticeably louder than the 58-70 dBA quiet class
  • 2.6 CFM is a nailing and inflation number, not a continuous-tool number
How this 3.2 was calculated
MetricScoreWeightBasis
Air flow3.640%2.6 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air2.325%6 gal x 150 PSI = 900, on a 125-3,500 scale
Noise2.415%78.5 dBA, on a 58-85 dBA scale
Portability5.010%No weight published - scored a neutral 5
Spec transparency3.310%2 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)
A yellow and black pancake air compressor with hose connected

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

Bostitch BTFP02012 published specifications
CFM @ 90 PSI2.6
CFM @ 40 PSINot published
Tank6 gal
Max pressure150 PSI
Noise78.5 dBA
Duty cycleNot published
RecoveryNot published
PumpOil-free
MotorNot published
WeightNot published
Power120V

Source: Bostitch BTFP02012 pancake compressor - distributor specification listing

Pick 4 - Porter-Cable C2002

3.6/10★★☆☆☆

Porter-Cable C2002

Best for: A first compressor for nailing, inflation and burst automotive work

Verdict

The default answer to 'cheapest useful compressor'. 6 gallons, 2.6 CFM, 150 PSI, and it has been the same machine for years.

What it does well

  • 2.6 CFM at 90 PSI and 3.7 at 40 - the most common spec in the budget class for a reason
  • 6-gallon tank at 150 PSI stores enough air for real bursts of impact work
  • Two couplers, so two people or two tools without swapping

What it will not do

  • Porter-Cable does not publish a noise figure for it; the class sits in the high 70s to low 80s dBA
  • 2.6 CFM will not run a ratchet, die grinder or sander continuously
How this 3.6 was calculated
MetricScoreWeightBasis
Air flow3.640%2.6 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air2.325%6 gal x 150 PSI = 900, on a 125-3,500 scale
Noise5.015%Manufacturer publishes no dBA figure - scored a neutral 5, not a guess
Portability5.010%No weight published - scored a neutral 5
Spec transparency3.310%2 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)
A red six-gallon pancake air compressor on a garage floor

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

Porter-Cable C2002 published specifications
CFM @ 90 PSI2.6
CFM @ 40 PSI3.7
Tank6 gal
Max pressure150 PSI
NoiseNot published
Duty cycleNot published
RecoveryNot published
PumpOil-free
Motor0.8
WeightNot published
Power120V

Source: Porter-Cable C2002 - product specifications

Pick 5 - Craftsman CMEC6150K

3.7/10★★☆☆☆

Craftsman CMEC6150K

Best for: Buying your first compressor and your first fittings in one go

Verdict

Same 2.6 CFM as every other pancake, bundled with the 13 accessories you would otherwise buy separately.

What it does well

  • 2.6 CFM at 90 PSI, 3.5 at 40 - identical working output to the rest of the pancake class
  • The 13-piece kit covers hose, chuck, blow gun and adapters, which is most of a starter setup
  • 30 lb, so it carries one-handed

What it will not do

  • 82 dBA published - the loudest figure in this roster
  • Kit accessories are entry grade; the hose in particular is the first thing to upgrade
How this 3.7 was calculated
MetricScoreWeightBasis
Air flow3.640%2.6 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air2.325%6 gal x 150 PSI = 900, on a 125-3,500 scale
Noise1.115%82 dBA, on a 58-85 dBA scale
Portability8.610%30 lb, on a 20-90 lb scale
Spec transparency6.710%4 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)
A pancake air compressor with hose and accessory fittings laid out beside it

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

Craftsman CMEC6150K published specifications
CFM @ 90 PSI2.6
CFM @ 40 PSI3.5
Tank6 gal
Max pressure150 PSI
Noise82 dBA
Duty cycleNot published
RecoveryNot published
PumpOil-free
Motor0.8
Weight30 lb
Power120V

Source: Craftsman CMEC6150K - product specifications

Pick 6 - WEN AP6092

3.6/10★★☆☆☆

WEN AP6092

Best for: Spending the least possible to reach the useful 6-gallon spec

Verdict

The cheapest way to get the standard 2.6 CFM / 150 PSI pancake spec. That is the whole pitch.

What it does well

  • 2.6 CFM at 90 PSI and 3.6 at 40 - the class spec, at the bottom of the class price
  • Two 1/4-inch NPT quick couplers and two gauges
  • Oil-free, so no maintenance routine to forget

What it will not do

  • WEN does not publish a noise figure for it
  • 11.5 A draw is the highest of the 6-gallon units here - worth knowing on an older circuit
How this 3.6 was calculated
MetricScoreWeightBasis
Air flow3.640%2.6 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air2.325%6 gal x 150 PSI = 900, on a 125-3,500 scale
Noise5.015%Manufacturer publishes no dBA figure - scored a neutral 5, not a guess
Portability5.010%No weight published - scored a neutral 5
Spec transparency3.310%2 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)
A compact oil-free pancake compressor with two gauges

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

WEN AP6092 published specifications
CFM @ 90 PSI2.6
CFM @ 40 PSI3.6
Tank6 gal
Max pressure150 PSI
NoiseNot published
Duty cycleNot published
RecoveryNot published
PumpOil-free
Motor11.5 A motor (HP not published)
WeightNot published
Power120V

Source: WEN AP6092 - product specifications

4.0 CFM in a pancake

The one that breaks the class ceiling

One unit in this class publishes 4.0 CFM at 90 PSI and a 200 PSI maximum, which is 54% more flow and a third more stored air per gallon than the rest of the field. It does this with a higher-pressure pump, and it pays for it in weight: 41 pounds against 30 for a conventional pancake.

The practical effect is that it clears the published average demand for a 1/2-inch impact wrench and a 3/8-inch ratchet, which no 2.6 CFM pancake does. If air tools are the reason you are buying a pancake, this is the one that changes the answer.

The honest caveat: its manufacturer publishes no noise figure, and high-pressure pumps are not quiet. If you are buying a pancake for an attached garage, the 75.5 dBA unit is the safer choice and you give up the flow.

Metabo HPT EC914S (THE TANK): what it runs

Delivered flow: 4 CFM at 90 PSI. We call a tool covered when delivered flow clears its highest published demand plus a 25% margin.

Runs it (4)

  • Brad nailer, 18 gaugeYes - needs 0.5 CFM, burst duty
  • Framing nailer, 21 or 30 degreeYes - needs 2.5 CFM, burst duty
  • Tire inflationYes - needs 2 CFM, intermittent duty
  • Impact wrench, 1/2"In bursts only - needs 5 CFM, burst duty

Does not run it (2)

  • Air ratchet, 3/8"No - needs 4 CFM, intermittent duty
  • Die grinder, 1/4"No - needs 6 CFM, continuous duty

Demand figures from the air tool CFM chart, which cites every one of them.

Format comparison

Pancake versus the alternatives

Against a hot dog (single horizontal cylinder): pancakes are more stable and usually cheaper for the same volume; hot dogs are narrower and fit a truck box better. The pump specs are typically identical.

Against a twin stack: twin stacks put the same volume into a taller, narrower footprint and are usually a little heavier. A quiet twin stack at 2.0 CFM and 60 dBA is a genuinely different proposition from a 2.6 CFM pancake at 82.

Against a 20-gallon vertical: no contest on storage, and no contest the other way on portability. The pancake wins on the thing that decides whether you use it at all, which is whether it is already sitting where you need it.

FAQ

Questions people actually ask

What is the best pancake air compressor for the money?

At 2.6 CFM the class is effectively tied on flow, so buy on the pressure ceiling and the noise figure: a 6-gallon unit at 165 PSI and 75.5 dBA is the best combination of those. If you need more air, one pancake publishes 4.0 CFM at 200 PSI and is worth the extra weight.

Is a pancake compressor good for air tools?

For burst tools, yes. A 2.6 CFM pancake breaks lug nuts and drives every nailer. It does not run a ratchet held down, a die grinder or a sander. The 4.0 CFM high-pressure pancake covers noticeably more ground.

Why is my pancake compressor so loud?

Direct-drive oil-free pumps running at high RPM in a thin steel shell are inherently noisy, and published figures in this class run from 75.5 to 82 dBA. If noise is the constraint, a quiet-series compressor at 60 dBA is a different machine - one that also delivers less flow.

How long does a pancake compressor last?

Oil-free pump life is finite by design, and California Air Tools is unusually open about publishing a figure - 3,000-plus hours before wear for its oil-free pumps. Most brands publish nothing. For intermittent home use that is many years; for continuous use it is not.

Can a pancake compressor fill car tires?

Easily. Tire inflation needs about 2 CFM at 30 to 60 PSI, well inside what a 2.6 CFM pancake supplies at a much higher pressure. If tires are the only reason you want a compressor though, a 12V inflator that lives in the car is the better tool.

Sources

Where these numbers come from

Accessed September 2026. If a figure on this page does not match the manufacturer's current sheet, tell us at contact@psiandhose.com and we will correct and date the change - see our editorial policy.

Read next

Related on Psi & Hose
