What size air compressor do I need for a plasma cutter?

Plasma is the one application where we will not print a CFM figure, because no reference we cite publishes one for the tool class and your own machine's data plate holds the answer. What we can do is tell you how to read it and which compressors clear the band plasma cutters live in.

By Ryder M.Last updated October 6, 2026Published 2026

Sparks from a cutting operation in a workshop

Some links on this page are affiliate links. If you buy through one, Magoo Media Group earns a commission from the retailer at no extra cost to you. It never changes which product we rank first - how this site is funded.

Read this first

The honest answer

The number you need is printed on your plasma cutter, not in an article. Every cutter states a required air supply - a flow figure and a pressure figure together, usually as SCFM at a specific PSI - and that pair is the specification your compressor has to meet. It varies by amperage, by torch, by consumable set and by manufacturer, which is precisely why a single number quoted on a buying-advice page is worthless to you.

This site does not invent figures. Our tool-demand dataset is built from two published references - Ingersoll Rand's air consumption chart for automotive service shops and Engineering ToolBox's air tool consumption table - and neither publishes a plasma-cutting class. So we carry no number for it, the same way we carry no lifespan figure for compressors because no manufacturer publishes one.

What we can say with confidence is structural. Plasma cutting is continuous duty: the air flows for as long as the arc is lit, with no pause for a tank to refill. It also has a pressure requirement that must be met at the torch while that flow is happening, which is a harder test than either number alone. And it is intolerant of moisture and oil in a way few other applications are, because contaminated air destroys consumables and spoils cut quality.

Where your number actually is

Look for an 'air supply', 'air requirement' or 'recommended air supply' line on the data plate, in the manual, or on the manufacturer's spec page. It will read something like a flow in SCFM at a stated PSI. Size your compressor against that figure as a continuous demand, not a burst one - and then leave margin, because a compressor running at exactly its rating is a compressor running at 100% duty.

The four things that matter

What to look for in the compressor

01Delivered CFM at 90 PSI, not horsepower and not maximum PSI. This is the only figure that tells you how much air the machine actually produces, and it is the one a weak listing omits. Compare it directly against your cutter's stated requirement.
02Pressure headroom above the torch requirement. The compressor has to supply your cutter's required PSI at the torch while flowing, which means the tank's cut-out pressure needs to sit comfortably above it - and remember that your regulator, filters and hose all take a share on the way.
03Duty cycle, and the willingness of the brand to publish one. Continuous demand against a pump with no duty statement is a guess. Two machines in our roster publish duty cycles; most do not.
04Pump type. Continuous duty favours an oil-lubricated pump, because the oil bath carries heat out of the cylinder. An oil-free pump relies on dry self-lubricating materials and runs hotter by design, which is the wrong trade for a tool that runs for minutes at a time.

The picks

Compressors that clear the band

Quick picks

#	Product	Best for	Score	Price
1	Industrial Air ILA3606056 60-gallon11.5 CFM @ 90 / 60 gal / 155 PSI11.5 CFM at 90 PSI. Included as the reference point for what continuous sanding and blasting actually costs.	Body work, blasting, or running two tools at once	8.1/10★★★★☆	Check price on Amazon #ad Disclosure - we do not publish prices we cannot verify
2	DEWALT DXCMLA1983054 30-gallon5.7 CFM @ 90 / 30 gal / 155 PSI5.7 CFM, 30 gallons, oil-lubricated cast iron and belt drive. Where a garage compressor stops being disposable.	A permanent garage compressor you expect to keep for a decade	7.9/10★★★★☆	Check price on Amazon #ad Disclosure - we do not publish prices we cannot verify
3	Motor Guard M-601/2" NPT / 0.01 micron / Up to 100 CFM at 80 PSI0.01 micron at up to 100 CFM. The last filter before the gun when you are spraying or running a plasma cutter.	Final-stage filtration for paint and plasma	5.6/10★★★☆☆	Check price on Amazon #ad Disclosure - we do not publish prices we cannot verify
4	PneumaticPlus SAU430 three-stage1/2" NPT / 10 micron particulate filter / 0.1 micron mist separator10 micron, then 0.1 micron mist separator, then regulator. The honest minimum before a spray gun.	Spraying paint or clear coat from a garage compressor	5.6/10★★★☆☆	Check price on Amazon #ad Disclosure - we do not publish prices we cannot verify

Scores are computed from manufacturer-published specs by the rubric on our methodology page. Nothing here has been bench-tested, and we do not publish prices we cannot verify.

Pick 1 - Industrial Air ILA3606056

8.1/10★★★★☆

Industrial Air ILA3606056 60-gallon

Best for: Body work, blasting, or running two tools at once

Verdict

11.5 CFM at 90 PSI. Included as the reference point for what continuous sanding and blasting actually costs.

What it does well

11.5 CFM at 90 PSI and 13.4 at 40 - clears an orbital sander with margin
Cast-iron twin-cylinder pump on a 60-gallon vertical tank
3.7 HP on 240V

What it will not do

240V and stationary: this is an electrical project, not a purchase
Overkill for anyone whose honest tool list is nailers, tires and a 1/2-inch impact - which is most people reading this

How this 8.1 was calculated

Metric	Score	Weight	Basis
Air flow	10.0	40%	11.5 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air	10.0	25%	60 gal x 155 PSI = 9300, on a 125-3,500 scale
Noise	5.0	15%	Manufacturer publishes no dBA figure - scored a neutral 5, not a guess
Portability	5.0	10%	No weight published - scored a neutral 5
Spec transparency	3.3	10%	2 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)

A large stationary vertical sixty-gallon air compressor in a workshop

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

Industrial Air ILA3606056 60-gallon published specifications
CFM @ 90 PSI	11.5
CFM @ 40 PSI	13.4
Tank	60 gal
Max pressure	155 PSI
Noise	Not published
Duty cycle	Not published
Recovery	Not published
Pump	Oil-lubricated
Motor	3.7
Weight	Not published
Power	240V

Source: Industrial Air ILA3606056 - product specifications

Pick 2 - DEWALT DXCMLA1983054

7.9/10★★★★☆

DEWALT DXCMLA1983054 30-gallon

Best for: A permanent garage compressor you expect to keep for a decade

Verdict

5.7 CFM, 30 gallons, oil-lubricated cast iron and belt drive. Where a garage compressor stops being disposable.

What it does well

5.7 CFM at 90 PSI and 7.0 at 40 - clears ratchets, die grinders and touch-up spraying
Oil-lubricated belt drive runs cooler and slower than a direct-drive oil-free pump
120/240V, so it can move to a 240V circuit later

What it will not do

Oil-lubricated means an actual maintenance routine: check and change the oil
155 PSI on 30 gallons stores less than 175 PSI on 20 in some comparisons - check the math, not the tank

How this 7.9 was calculated

Metric	Score	Weight	Basis
Air flow	9.4	40%	5.7 CFM at 90 PSI, on a 0.7-6 CFM scale
Stored air	10.0	25%	30 gal x 155 PSI = 4650, on a 125-3,500 scale
Noise	5.0	15%	Manufacturer publishes no dBA figure - scored a neutral 5, not a guess
Portability	5.0	10%	No weight published - scored a neutral 5
Spec transparency	3.3	10%	2 of 6 useful figures published (CFM at 90, CFM at 40, dBA, duty cycle, recovery, weight)

A thirty-gallon belt-drive air compressor with a cast iron pump

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

DEWALT DXCMLA1983054 30-gallon published specifications
CFM @ 90 PSI	5.7
CFM @ 40 PSI	7
Tank	30 gal
Max pressure	155 PSI
Noise	Not published
Duty cycle	Not published
Recovery	Not published
Pump	Oil-lubricated
Motor	1.9
Weight	Not published
Power	120/240V

Source: DEWALT DXCMLA1983054 30-gallon compressor - product specifications

Pick 3 - Motor Guard M-60

5.6/10★★★☆☆

Motor Guard M-60

Best for: Final-stage filtration for paint and plasma

Verdict

0.01 micron at up to 100 CFM. The last filter before the gun when you are spraying or running a plasma cutter.

What it does well

0.01 micron - two orders of magnitude finer than a standard 10 micron water trap
Handles up to 100 CFM at 80 PSI, so it never restricts a garage system
The wound element is hydrophilic: it absorbs water and oil rather than just blocking particles

What it will not do

125 PSI maximum - it must sit downstream of a regulator, not on a 175 PSI tank outlet
The element (M-723) is a consumable, and a wet system eats them

How this 5.6 was calculated

Metric	Score	Weight	Basis
Pressure headroom	0.0	40%	125 PSI rating, on a 125-300 PSI scale
Flow capacity	10.0	40%	10080 SCFM, on a 40-100 SCFM scale
Spec transparency	8.0	20%	6 published specification figures

A cylindrical sub-micronic compressed air filter mounted to a wall bracket

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

Motor Guard M-60 published specifications
Port size	1/2" NPT
Filtration	0.01 micron
Flow	Up to 100 CFM at 80 PSI
Max pressure	125 PSI
Temperature range	32-175F
Replacement element	M-723

Source: Motor Guard M-60 sub-micronic compressed air filter - product specifications

Pick 4 - PneumaticPlus SAU430-N04G

5.6/10★★★☆☆

PneumaticPlus SAU430 three-stage

Best for: Spraying paint or clear coat from a garage compressor

Verdict

10 micron, then 0.1 micron mist separator, then regulator. The honest minimum before a spray gun.

What it does well

0.1 micron mist separator stage is the one that actually removes oil aerosol and sub-micron mist
Three stages in one modular body with a bracket and gauge
1/2" NPT, so it is not the restriction in a spray setup

What it will not do

Three elements to buy and replace instead of one
Does not dry air the way a refrigerated dryer or desiccant column does - it separates, it does not chill

How this 5.6 was calculated

Metric	Score	Weight	Basis
Pressure headroom	5.0	40%	No pressure rating published - scored a neutral 5
Flow capacity	6.0	40%	Flow not published for this class - scored a 6, which is what a correctly sized hose or fitting does not restrict
Spec transparency	6.0	20%	5 published specification figures

A three-stage compressed air filtration and regulation assembly mounted on a wall

Licensed stock photo - illustrative of the category, not a photo of this unit

Check price on Amazon

#ad Disclosure - we do not publish prices we cannot verify

Published specs

PneumaticPlus SAU430 three-stage published specifications
Port size	1/2" NPT
Stage 1	10 micron particulate filter
Stage 2	0.1 micron mist separator
Stage 3	Pressure regulator
Included	Bracket and gauge

Source: PneumaticPlus SAU430 three-stage air drying system - product specifications

The comparison

What our roster delivers

Read this table against your own cutter's stated figure rather than against a number we have supplied. The point of the table is the shape of the field: there is a hard step between what a 120V circuit can produce and what a 240V one can, and plasma is one of the applications that frequently lands on the far side of it.

Continuous-duty capability across our roster, manufacturer-published
Compressor	CFM @ 90	Tank	Max PSI	Pump	Supply	Duty cycle published
Industrial Air ILA3606056	11.5	60 gal	155	Oil-lubricated	240V	No
DEWALT DXCMLA1983054	5.7	30 gal	155	Oil-lubricated	120/240V	No
California Air Tools 10020C	5.3	10 gal	125	Oil-free	110V, 14 A	Yes - 70/30
Husky C201H	4.0	20 gal	175	Oil-free	120V	No
Porter-Cable C2002	2.6	6 gal	150	Oil-free	120V	No

Manufacturer-published figures. No plasma-cutting demand figure appears here because no source we cite publishes one.

Filtration

Air quality is not a secondary concern here

A compressor makes warm, wet air. The water condenses as that air cools in the tank and the line, and in plasma cutting it arrives at the torch, where it shortens consumable life and degrades the cut. This is the part of the setup that people skip and then replace tips over.

A plain 10 micron water trap is a useful first stage and not sufficient on its own. Our PneumaticPlus SAW300 publishes 53 SCFM and 10 micron filtration and is genuinely the most useful small purchase in a garage air system, but 10 micron does not take out oil aerosol or sub-micron mist. A three-stage assembly - 10 micron particulate, then a 0.1 micron mist separator, then a regulator - is the honest minimum, and the PneumaticPlus SAU430 is exactly that on 1/2-inch NPT.

For a final stage, the Motor Guard M-60 publishes 0.01 micron filtration at up to 100 CFM at 80 PSI, with a hydrophilic wound element that absorbs water and oil rather than merely blocking particles. Note its 125 PSI maximum: it must sit downstream of your regulator, never on a 175 PSI tank outlet. Its element is a consumable, and a wet system eats them - which is itself a diagnostic.

Buffer vs flow

Why the tank matters less than you would think

A tank is a buffer. It lets a tool draw faster than the pump produces for a short time, then the pump refills it. For burst tools that is the whole story - an impact wrench averages a published 4.2 CFM and draws 22 CFM at load, and it works on a 2.6 CFM pancake because you only hold the trigger for two seconds.

Plasma cutting does not work that way. The arc draws air continuously for as long as it is lit, so a bigger tank delays the moment the pump becomes your pace rather than removing it. Sixty gallons buys you a longer first cut; it does not buy you sustained capability that the pump cannot supply.

Which means the gallon figure is a secondary specification here and the CFM figure is the primary one. The reason the 60-gallon machine is the pick is not its volume - it is the 11.5 CFM printed next to it, which comes from a 3.7 HP motor on a 240V circuit. Buying volume while ignoring flow is the most common and most expensive mistake in this whole category.

Practical

Plumbing the supply so it actually arrives

Keep the hose short and wide. A hose is a restriction and the loss grows as diameter falls and length rises; a long 1/4-inch hose will cost you pressure at the torch that the compressor is genuinely producing at the tank.
Check your couplers are not the bottleneck. A standard 1/4-inch M-STYLE coupler publishes 40 SCFM, which is ample, but a 1/2-inch G-STYLE coupler publishes 99 SCFM if you are running a 1/2-inch line - and on a high-flow continuous application the fittings are worth checking rather than assuming.
Put the filtration between the compressor and the regulator, with the finest stage last and downstream of the regulator if its pressure rating requires it. Order matters and most people get it backwards.
Drain the tank before every session, not after. Water in the bottom of the tank is water on its way to your torch, and plasma is the application least willing to forgive it.
Let the compressor catch up between cuts rather than fighting it. If the pump never reaches cut-out, it is running at 100% duty, and no consumer machine in our roster is rated for that.
